EV diagnostic kit
Autel Ultra EV Highlights:
-
Upgraded from Autel MSUltra/ MS909EV/ MS919/ MS909/ Ultra Lite, Autel Ultra EV new energy scanner adds EVs diagnostics,EV high-voltage system diagnosis, battery pack offline analysis.
-
D-PDU/SAE J2534/RP1210/DoIP/CAN FD protocols are supported; Wider vehicle coverage for 99.99% makes in the market;
-
5-in-1 MaxiFlash VCMI integrates VCI, 4-channel oscilloscope, waveform generator, multimeter, and CAN bus tester functions
-
Advanced J2534 Programming and Coding, ECU upgrading & downgrading, ECU module matching & replacement, etc.
-
40+ service functions to fix all car-related problems, with no need to turn to other scan tools or gurus;
-
Pre & Post Scan: Makes it easy to document the vehicle's pre-repair and post-repair condition for insurance adjusters and service managers.
-
Built-in Oscilloscope & Multimeter
-
Support D-PDU/J2534/RP1210 Diagnostic Standards: VCMI adds support for these protocols, allowing connection to factory diagnostic scanners for diagnostics and ECU programming.
-
Topology Mapping 2.0: Provides a color-coded topology display for all vehicle systems' relationship on one page, helping you better analyze the system faults.
-
Split-screen multi-application navigation with super fast running speed, greatly improving your work efficiency;
-
10+ New Features: Support wider vehicle coverage, more frequent updates, WIFI print reports, Pre & Post scan, FCA & Renault SGW, report management, remote expert (* Sending us an SN code is required for us to add you to our whitelist and enable this feature.) and extended features such as battery test and Videoscope (with MV105/108). Enhanced Remote Expert: The remote expert adds DoIP protocol, making the model coverage wider; the server and point-to-point dual-channel connection method makes the network more stable and reduces communication delay. The scanner also supports protocols auto recognition, diagnostic reports import, and several communication methods such as audio and video for smoother communication.
-
Multiple repair guidance: Technical Service Bulletin (TSB), DTC Analysis, Repair Assist, Repair Tips, Component Measurement, and Relevant Cases;
-
Supported Language: English Only
-
1 Year free update online. Later Ultra is $899/year via Autel TCP
-
BMW service history update with Maxisys Ultra.
-
Oct. 2024. Adds VAG SFD security gateway unlock with online token
NOTE:
-
For customers who already bought MS909 or MaxiSys Ultra can just buy EV box to upgrade their device to MS909EV and MaxiSys Ultra EV.
-
The methods to active EV box on MS909/ MaxiSys Ultra: to imput EV box SN on tablets portal directly to upgrade.
-
* You have to have an Active Subscription in order to access the Autel servers.
If you're trying to offline SCN program a Benz or BMW, you'll need an active subscription.
UltraEV recent update:
Now you have access to online programming 26 car makes!
NO matter the origin of the car, AUTEL got you covered.
Supported car makes
Mercedes Benz, BMW, VW, Audi, Skoda, Land rover, Jaguar, Porsche, Renault, Nissan, Infiniti, Subaru, Hyundai, Kia, Great Wall, GAC Trumpchi, Roewe MG, Geely, Mahindra (India ONLY), BMW Brilliance, Shanghai VW, FAW VW, China General Motors, Beijing Hyundai, Yueda Kia
ULTRA EV Key Benefits:
-
Rapid analysis of high-voltage systems
-
Battery State of Charge & State of Health diagnostics
-
Step-by-step system disassembly instructions
-
Safe, detailed connection guidance for secure testing
-
Cloud-based Data Manager to organize your customer info and vehicle records
AUTEL Ultra Introduction
The MaxiSys Ultra is Autel's most ambitious diagnostics tablet designed to maximize technician intelligence. It features a 12.9-inch touchscreen tablet with Android 7.0 OS powered by an Octa-core processor (2.3GHz Quad + 1.7GHz Quad), substantial 256GB built-in memory, all powering the new split-screen multi-application navigation to provide diagnostic guidance and test components to confirm repairs. Combined with the dynamic topology module mapping, enhanced AutoSCAN features options, the Ultra offers the technicians step-by-step repair guidance. The new MaxiFlash VCMI functions as a 4-channel oscilloscope, waveform generator, multimeter, and CAN BUS tester. The convenient docking station featured ensures you always have the power to scan
Top-level Configurations, OE-level Topology Module Tree
The new Topology Module Listing CAN BUS Tree, specially designed for the OEM diagnostic tools, shows all available control units of the test vehicle in different colors, helping users get to know the numbers of systems, the scanned systems, and the scan results at a glance.
The new MaxiFlash VCMI (Vehicle Communication and Measurement Interface) integrates those specialty functions into one: oscilloscope, waveform generator, multimeter, and digital OBDII breakout box.
Autel EV Diagnostics Upgrade Kit Highlights
1. Used with Maxisys Ultra/ MS909/ MS919
2. Mainly for Specific Electric Vehicles to Perform Battery Pack Analysis
3. Method to Active EV Box on MS909/ MaxiSys Ultra: to Input EV Box SN on Tablets Portal Directly to Upgrade.
4. The EV Battery Pack Diagnostic Software Upgrade Will Receive Updates When the Tablet's Total Care Program (TCP) Subscription is Active
What is Autel EVDIAG?
Use the Autel MaxiSYS EVDiag Upgrade Kit (EVDIAGKIT) to diagnose battery pack State of Charge and State of Health on BMW, Tesla and VW electric vehicles.
The EV Diagnostics Upgrade Kit includes EVDiag Box and adapters for specific electric vehicles to perform battery pack analysis. The EVDiag Box is compatible with the MaxiSys Ultra, MaxiSys Ultra ADAS, MaxiSys MS919, and MaxiSys MS909 tablets. EVDiag Box connects to MaxiFlash VCI or VCMI.
The EVDiag Upgrade Kit is compatible with Autel Ultra-series tablets (Ultra, Ultra ADAS, MS919, MS909 — sold separately).
The EV battery pack diagnostic software upgrade will receive updates when the tablet's Total Care Program (TCP) subscription is active.
Features
-
Includes EVDiag Box, Adapters for BMW, Tesla, VW and Breakout Leads
-
Includes Carrying Case
-
Compatible with Ultra series products to perform Battery Pack diagnostics
-
State of Charge and State of Health analysis for true battery condition
Autel Ultra EV: Revolutionary Solution for EVs
Why Autel has Developed Special Diagnostic Tools for New Energy Vehicles?
-
The car structure of EVs is different from f-uel cars: Unlike f-uel vehicles, the problems of new energy vehicles are not scattered among the various systems but are mainly focused on the electronic control system and the battery. Traditional diagnostic scanners are unable to conduct comprehensive problem troubleshooting for electric vehicles.
-
Traditional scanners cannot diagnose EVs: They cannot diagnose the high-voltage system of EVs; obtain detailed information on each module of the battery pack and locate faults, or diagnose electric control modules such as motors.
-
Insufficient experience in EV diagnostics: Due to the high technical requirements for mechanics and the danger of the operation, there are currently few mechanics who can perform the diagnostics for EVs. Our scanner Ultra EV, as an expert, can provide video graphics as well as guidance and safety tips for you.
-
In this way, we have developed the EV box and a set of adapters to meet the diagnostic needs of new energy vehicles, diagnose the high-voltage system and perform battery pack analysis.
How can Ultra EV help you with new energy vehicles diagnostics?
Display an all-in-one status of the battery pack's State of Charge (SoC), State of Health (SoH), overall voltage and temperature, and a detailed analysis of each battery module.
Battery pack maintenance recommendations are provided based on the monitoring of voltage averages and differences as well as the maximum and minimum voltages of the battery module.
One-stop information source for all these vehicles with detailed battery information, including battery brand and module locations, and system block diagram with component introduction and connection, socket diagram, and disassembly guides.
In-depth safety information and step-by-step inspection guidance to ensure technicians can diagnose, service, and repair these vehicles safely and efficiently.
Package List:
1pc x Ultra Main Unit
1pc x MaxiFlash VCMI
1pc x Main Cable V2.0
1pc x USB 2.0 Cable V2
1pc x AC/DC Adapter(12V)
1pc x Cigarette Lighter
2pcs x Light Fuse 6x30mm
1pc x Clipper Cable
4pcs x Scope Test Lead
2pcs x Multimeter Test Lead
2pcs x Secondary Ignition Pickup
2pcs x Attenuator 20:1
1set x Breakout Lead 4x6 PCS
2pcs x Multimeter Probe
1set x Flexible Back-pinning Probe 2x2 PCS
1set x Back-pinning Probe - Red/Green/Blue/Yellow/Black 1x5 PCS
2pcs x Back-pinning Probe Screw
20pcs x Back-pinning Probe Replacement Needle
1set x Small Crocodile Clip 2x2 PCS
1set x Large Dolphin Clip 1x2 PCS
1pc x Quick Reference Guide
1pc x Packing List
1pc x Soft Cloth
1pc x Tool Box
1pc x Carrying Case
1pc x EVDiag Box
1pc x Adapter BPTC0101/01
1pc x Adapter BPTC0205/01
6pcs x Breakout Lead 1
1pc x Adapter BPTC0102/01
1pc x Adapter BPTC1101/01
6pcs x Breakout Lead 2
1pc x Adapter BPTC0103/01
1pc x Adapter BPTC1102/01
6pcs x Breakout Lead 3
1pc x Adapter BPTC0201/01
1pc x DB25 Snake Cable BPTJ0001/01
6pcs x Breakout Lead 4
1pc x Adapter BPTC0202/01
1pc x Packing List
1pc x EVDiag Box Main Cable BPTC0001/01
1pc x Adapter BPTC0203/01
1pc x Quick Reference Guide
3pcs x Breakout Lead Extension Cord
1pc x Adapter BPTC0204/01
1pc x Carrying Case 634x170x404mm
4pcs x Dual Banana Plug
